Main Characteristics
1.Full servo independent control manufacturing, simple touch screen operation, it is safe and reliable.
2.Unwinding adopts constant tension control for automatic unwinding, winding adopts stepper motor and magnetic powder for winding.
3.Working procedures:
Uncoiling—— adhesive plaster peeling—— adding absorbent pad(∮16mm)—— covering with release paper—— infusion bottle sticker positioning hobbing(∮28mm semi-cutting)—— product contiguous cutting off(hobbing)—— conveyor contiguous infusion bottle sticker step by counting output.
4.Equipment use: suitable for producing infusion bottle sticker.
5.Scope of application: suitable for infusion bottle stickers with PE adhesive tape, PVC adhesive tape, etc. as base material.
Main technical parameters
|
Model
|
H-800
|
Max diameter of material roll
|
380mm
|
Max width of adhesive tape
|
90mm
|
Absorbent cotton
|
∮16mm
|
Shape of infusion bottle sticker
|
∮28mm
|
Quantity
|
4 patches
|
Packaging speed
|
0-800patches/min
|
Power
|
4KW
|
Voltage
|
380V
|
Dimension
|
3800*700*1900mm
|
Weight
|
1600KG
|
|
